XV-460-57TQB

الوصف

Touch panel, ir, 24 V DC, 5.7z, TFTcolor, ethernet, RS232, CAN, (PLC)

Catalog No: 139897

Display – Type : Color display, TFT

Touch technology:, Infra-red touch.

Number of colours : Adjustable: 65536 or 256 colours.

Resolution : QVGA 320 x 240.

Screen diagonal : 5.7 inch.

Operating system : Windows CE (license required), CompactFlash card required.

built-in interfaces :

• • 1 x Ethernet 100base-TX/10base-T.
  • 1 x RS232.
  • 1 x CAN.
  • 1 x USB host.
  • 1 x USB device.

Visualisation software :

• GALILEO.
• EPAM.
• XSOFT-CODESYS-2.
• XSOFT-CODESYS-3.

PLC-Programming software

• XSOFT-CODESYS-2.
• XSOFT-CODESYS-3.
